Dell E193FPc User Manual

Dell E193FPc
56
U105 56L 585 4 AIC1117-33CY
U106 56G 563 27 AIC1117A-18CY SOT-223
715L1408 1 PCB
CN101 95G8014 8 21 WIRE HARNESS
LED1 81L 12 1A GP LED
R101 61L 60210152T 100OHM +- 5% 1/6W
SW101 77L 600 4 HJ TACT SWITCH TSPE-1
SW102 77L 600 4 HJ TACT SWITCH TSPE-1
SW103 77L 600 4 HJ TACT SWITCH TSPE-1
SW104 77L 600 4 HJ TACT SWITCH TSPE-1
PW1942LGD1SMT POWER BOARD FOR SMT
40L 45762420A ID LABEL
71L 55 2 A FERRITE BEAD 6.5*5*1.7
705L 560 57 DL D910/D911 ASS'Y
705L 560 61 06 R903 ASS'Y
705L 780 57 DL Q903 ASS'Y
705L 780 61 07 R917 ASS'Y
705L1742 HL BD901/C903/IC901 ASS'Y
C213 63L210J1842A2 PMS 0.18UF 250V
C214 63L210J1842A2 PMS 0.18UF 250V
C226 65L 3J2206ET 22PF 5% 3KV TDK
C227 65L 3J2206ET 22PF 5% 3KV TDK
C228 65L 3J2206ET 22PF 5% 3KV TDK
C229 65L 3J2206ET 22PF 5% 3KV TDK
C901 65L305M2222EM 2200PF+-20% 250VAC/400V
C902 65L305M2222EM 2200PF+-20% 250VAC/400V
C904 67L215S10115K 100UF 450V
C913 65L306M3322F2 3300PF +-20% 400VAC Y1
C922 67L215L102 4N KY25VB1000M-L 12.5*20
C923 67L215C102 3H EC LESR 1000UF16V HERME
CN901 33G8029 4A PLUG
CON102 95G8014 6 19 WIRE HARNESS
CON201 33L8021 2D AC CONN.2P R/A 87210-0236
CON202 33L8021 2D AC CONN.2P R/A 87210-0236
CON203 33L8021 2D AC CONN.2P R/A 87210-0236
CON204 33L8021 2D AC CONN.2P R/A 87210-0236
IC902 56L 139 3B PC123 Y82
L201 73G 253139 HA CHOKE COIL
L202 73G 253139 HA CHOKE COIL
L203 73L 174 30YSA FILTER

Dell E193FPc Specifications

General

Brand	Dell
Model	E193FPc
Category	Monitor
Language	English
