IfyouhaveVESA'sDPM™compliancedisplaycardorsoftwareinstalledinyourPC,themonitorcanautomaticallyreduceitspowerconsumptionwhennotin
use. This is referred to as 'Power Save Mode'*. If input from keyboard, mouse, or other input devices is detected by the computer, the monitor automatically
'wakes up'. The following table shows the power consumption and signaling of this automatic power saving feature:
Activate the computer and 'wake up' the monitor to gain access to the OSD.
* Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the monitor.
Pin Assignments
15-pin D-Sub connector
24-pin Digital-Only DVI Connector
NOTE: The OSD only functions in the 'normal operation' mode. One of the following messages appears when the “menu” or “plus”
1: Auto detect
In Power Save Mode
Press computer power button
or any key on keyboard or move mouse
2: Analog Input
In Power Save Mode
Press computer power button
or any key on keyboard or move mouse
3: Digital Input
In Power Save Mode
Press computer power button
or any key on keyboard or move mouse
This monitor is ENERGY STAR®-compliant as well as TCO '99 power management compatible.
Monitor Side of the 15-pin Side Signal Cable
To Next Page
