Jumpers and Connectors 117
Table 6-2. System Board Jumpers and Connectors
Item Connector Description
13
1
4
2
Memory module slot 3
Memory module slot 1 (white release lever)
Memory module slot 4
Memory module slot 2 (white release lever)
2 CPU Processor
3 IO_RISER1 Expansion-card riser connector
4 iDRAC6 Enterprise iDRAC6 Enterprise card connector
5 iDRAC6 Express iDRAC6 Express card connector
6SATA_E
SATA_D
SATA_C
SATA_B
SATA_A
SATA connector E
SATA connector D
SATA connector C
SATA connector B
SATA connector A
7PWRD_EN
NVRAM_CLR
Password enable jumper
NVRAM clear jumper
8 HD_ACT_CARD Expansion-card cable connector
9 FAN3 System fan 3 connector
10 Battery Battery socket
11 USB_CONN Internal USB connector
12 CTRL_PNL Control panel connector
13 FAN2 System fan 2 connector
14 FAN1 System fan 1 connector
15 12V 4-pin power connector
16 PWR_CONN 24-pin power connector
