Installing System Components 77
Figure 3-14. Removing and Installing an iDRAC6 Express Card
7
If applicable, reinstall the expansion card. See "Installing an Expansion
Card" on page 62.
8
Close the system. See "Closing the System" on page 51.
9
Reconnect the system to its electrical outlet and turn the system on,
including any attached peripherals.
1 iDRAC6 Express card 2 plastic standoff tab
3tab 4clip
book.book Page 77 Monday, March 7, 2011 2:24 PM
