Learn more at Dell.com/Networking
SS794_Dell_Force10_Switch_25V_50V_092311
Specifications: S-Series Power-over-Ethernet Switches
Ordering Information
Order Number Description
S25-01-GE-24V 24-port 10/100/1000Base-T chassis
with 4 SFP ports, 2 modular slots,
1AC+ 1 DC power supply, FTOS software
S50-01-GE-48T-V-2 48-port 10/100/1000Base-T chassis with
PoE, 4 SFP ports, 2 modular slots, 1AC+ 1
DC power supply, FTOS software
S50-01-10GE-2P 2-port 10 GbE XFP module
S50-01-10GE-2C 2-port 10 GbE CX4 module
S50-01-12G-2S 2-port 12 Gbps stacking module
S50-01-24G-1S 1-port 24 Gbps stacking module
S50-01-SSC-12G 60 cm stacking cable for S50-01-12G-2S
S50-01-LSC-12G 4 m stacking cable for S50-01-12G-2S
S50-01-SSC-24G 60 cm stacking cable for S50-01-24G-1S
S50-01-LSC-24G 4 m stacking cable for S50-01-24G-1S
S50-01-PSU-V S25V/S50V redundant power supply unit
SW-SB-LATEST Layer 3 FTOS software upgrade
Physical
S25N: 24 line-rate 10/100/1000Base-T ports
S50N: 48 line-rate 10/100/1000Base-T ports
4 SFP ports (shared)
1 RJ45 console/management port with RS232 signaling
Optional modules:
2 line-rate ports 10 Gigabit Ethernet XFP
2 line-rate ports 10 Gigabit Ethernet CX4
2 line-rate ports 12 Gigabit Stacking
1 line-rate port 24 Gigabit Stacking
Size: 1 RU, 1.7 h x 17.32 w x 16.73” d (4.3 h x 44 w x 42.5 cm d)
Weight: 15.62 lbs (7.10 kg)
ISO 7779 A-weighted sound pressure level:
S25V: 42.9 dBA at 73.4°F (23°C), S50V: 62.2 dBA at 73.4°F (23°C)
Power supply: 100–240 VAC 50/60 Hz, –48 VDC
Max. thermal output: S25V: 349 BTU/h, S50V: 497 BTU/h
Max. current draw per System:
6.5 A at 100/120 VAC, 3.25 A at 200/240 VAC, 11.5 A at -48 VDC
Max. current draw per system:
2 A at 100/120 VAC, 1 A at 200/240 VAC, 3.6 A at -48 VDC
Max. power consumption:
S25V: 102 W, S50V: 146 W
Max. PoE power:
320 W using either AC or DC inputs
790 W using load sharing AC and DC inputs
Max. operating specifications:
Operating temperature: 32°to 122°F (0°to 50°C)
Operating humidity: 10 to 85% (RH), non-condensing
Max. non-operating specifications:
Storage temperature: –40°to 158°F (–40°to 70°C)
Storage temperature: –40°to 158°F (–40°to 70°C)
Reliability: S25V: MTBF 107,720 hours, S50V: MTBF 130,482 hours
Redundancy
Ring stacking topology with dynamic master election
Dual modular slots with up to four 10 GbE ports
Link aggregation across stack members
Power redundancy
Performance
MAC addresses: S25N: 16K, 50V: 32K
IPv4 routes: 4K
IPv6 routes: 2,500
Switching fabric capacity: S25V: 144 Gbps, S50V: 288 Gbps
User trac capacity: S25V: 128 Gbps (95 Mpps)
S50V: 176 Gbps (131 Mpps)
Link aggregation: 8 links per group, 128 groups per stack
Stacking capacity: 96 Gbps per stack member
Queues per port: 4 queues
VLANs: 1024 VLANs with 4096 tag value support
Line-rate Layer 2 switching: all protocols, including IPv4 and IPv6
Line-rate Layer 3 routing: IPv4 and IPv6
LAG load balancing: based on Layer 2, IPv4 or IPv6 headers
Switching latency: <5 µs for 64 byte frames
IEEE Compliance
802.1AB LLDP
802.1ag Connectivity Fault Management
802.1D Bridging, STP
802.1p L2 Prioritization
802.1Q VLAN Tagging, Double VLAN Tagging, GVRP
802.1s MSTP
802.1w RSTP
802.1X Network Access Control
802.3ab Gigabit Ethernet (1000BASE-T)
802.3ac Frame Extensions for VLAN Tagging
802.3ad Link Aggregation with LACP
802.3ae 10 Gigabit Ethernet (10GBASE-X)
802.3ak 10 Gigabit Ethernet (10GBASE-CX4)
802.3i Ethernet (10BASE-T)
802.3u Fast Ethernet (100BASE-TX)
802.3x Flow Control
802.3z Gigabit Ethernet (1000BASE-X)
ANSI/TIA-1057 LLDP-MED
Force10 FRRP (Force10 Redundant Ring Protocol)
Force10 PVST+
MTU 9,252 bytes
RFC and I-D Compliance
General Internet Protocols
768 UDP 1321 MD5
793 TCP 1350 TFTP
854 Telnet 2474 Dierentiated Services
959 FTP 3164 Syslog
General IPv4 Protocols
791 IPv4 1812 Routers
792 ICMP 1858 IP Fragment Filtering
826 ARP 2131 DHCP (relay)
1027 Proxy ARP 2338 VRRP
1035 DNS (client) 3021 31-bit Prefixes
1042 Ethernet Transmission 3046 DHCP Option 82
1191 Path MTU Discovery 3069 Private VLAN
1305 NTPv3 3128 Tiny Fragment Attack
1519 CIDR Protection
1542 BOOTP (relay)
General IPv6 Protocols
1981 Path MTU Discovery 2463 ICMPv6
(partial) 1858 IP Fragment Filtering
2460 IPv6 2675 Jumbograms
2461 Neighbor Discovery 3587 Global Unicast
(partial) Address Format
2462 Stateless Address 4291 Addressing
Autoconfiguration
(partial)
RIP
1058 RIPv1 2453 RIPv2
OSPF
2154 MD5 3623 Graceful Restart
1587 NSSA 4222 Prioritization and
2328 OSPFv2 Congestion Avoidance
2370 Opaque LSA
BGP
1997 Communities 2918 Route Refresh
2385 MD5 3065 Confederations
2439 Route Flap Damping 4360 Extended Communities
2796 Route Reflection 4893 4-byte ASN
2842 Capabilities 5396 4-byte ASN
2858 Multiprotocol Extensions Representation
draft-ietf-idr-bgp4-20 BGPv4
draft-ietf-idr-restart-06 Graceful Restart
Multicast
1112 IGMPv1
2236 IGMPv2
3376 IGMPv3
3569 SSM for IPv4
4541 IGMPv1/v2 Snooping
draft-ietf-pim-sm-v2-new-05 PIM-SM
Network Management
1155 SMIv1
1156 Internet MIB
1157 SNMPv1
1212 Concise MIB Definitions
1215 SNMP Traps
1493 Bridges MIB
1850 OSPFv2 MIB
1901 Community-based SNMPv2
2011 IP MIB
2012 TCP MIB
2013 UDP MIB
2096 IP Forwarding Table MIB
2570 SNMPv3
2571 Management Frameworks
2572 Message Processing and Dispatching
2574 SNMPv3 USM
2575 SNMPv3 VACM
2576 Coexistence Between SNMPv1/v2/v3
2578 SMIv2
2579 Textual Conventions for SMIv2
2580 Conformance Statements for SMIv2
2618 RADIUS Authentication MIB
2665 Ethernet-like Interfaces MIB
2674 Extended Bridge MIB
2787 VRRP MIB
2819 RMON MIB (groups 1, 2, 3, 9)
2863 Interfaces MIB
2865 RADIUS
3273 RMON High Capacity MIB
3416 SNMPv2
3418 SNMP MIB
3434 RMON High Capacity Alarm MIB
3580 802.1X with RADIUS
5060 PIM MIB
ANSI/TIA-1057 LLDP-MED MIB
draft-grant-tacacs-02 TACACS+
draft-ietf-idr-bgp4-mib-06 BGP MIBv1
IEEE 802.1AB LLDP MIB
IEEE 802.1AB LLDP DOT1 MIB
IEEE 802.1AB LLDP DOT3 MIB
ruzin-mstp-mib-02 MSTP MIB (traps)
sFlow.org sFlowv5
sFlow.org sFlowv5 MIB (version 1.3)
FORCE10-BGP4-V2-MIB Force10 BGP MIB
(draft-ietf-idr-bgp4-mibv2-05)
FORCE10-IF-EXTENSION-MIB
FORCE10-LINKAGG-MIB
FORCE10-COPY-CONFIG-MIB
FORCE10-MON-MIB
FORCE10-PRODUCTS-MIB
FORCE10-SS-CHASSIS-MIB
FORCE10-SMI
FORCE10-SYSTEM-COMPONENT-MIB
FORCE10-TC-MIB
FORCE10-TRAP-ALARM-MIB
Regulatory Compliance
Safety
UL/CSA 60950-1, 1st Edition
EN 60950-1, 1st Edition
IEC 60950-1, 1st Edition Including all National Deviations
and Group Dierences
EN 60825-1 Safety of Laser Products Part 1: Equipment
Classification Requirements and User’s Guide
EN 60825-2 Safety of Laser Products Part 2:
Safety of Optical Fibre Communication Systems
FDA Regulation 21 CFR 1040.10 and 1040.11
Emissions
Australia/New Zealand: AS/NZS CISPR 22: 2006, Class A
Canada: ICES-003, Issue-4, Class A
Europe: EN 55022: 2006+A1:2007 (CISPR 22: 2006), Class A
Japan: VCCI V3/2009 Class A
USA: FCC CFR 47 Part 15, Subpart B:2009, Class A
Immunity
EN 300 386 V1.4.1:2008 EMC for Network Equipment
EN 55024: 1998 + A1: 2001 + A2: 2003
EN 61000-3-2: Harmonic Current Emissions
EN 61000-3-3: Voltage Fluctuations and Flicker
EN 61000-4-2: ESD
EN 61000-4-3: Radiated Immunity
EN 61000-4-4: EFT
EN 61000-4-5: Surge
EN 61000-4-6: Low Frequency Conducted Immunity
RoHS
All S-Series components are EU RoHS compliant
The features and specifications are for FTOS. For SFTOS features
and specifications, please refer to the SFTOS data sheet..
