Dell Force10 S25N - S25 N and PS4100 Point-to-Point Cable Connections

S25N and PS4100 point to point cable connections
Switch 1
Port
To
Switch 2
Port
To
1 Server 1, port 1
1 Server 1, port 2
2 Server 1, port 3*
2 Server 1, port 4*
3 Server 2, port 1
3 Server 2, port 2
4 Server 2, port 3* 4 Server 2, port 4*
5 Server 3, port 1
5 Server 3, port 2
6 Server 3, port 3*
6 Server 3, port 4*
7 Server 4, port 1
7 Server 4, port 2
8 Server 4, port 3* 8 Server 4, port 4*
Array 3
17 Controller 0, port 0
17 Controller 0, port 1
18 Controller 1, port 1 18 Controller 1, port 0
Array 2
19 Controller 0, port 0
19 Controller 0, port 1
20 Controller 1, port 1 20 Controller 1, port 0
Array 1
21 Controller 0, port 0
21 Controller 0, port 1
22 Controller 1, port 1 22 Controller 1, port 0
24 OOB Mgmt
* Use of the 3rd and 4th host ports is optional. At least two ports are required.
