Appendix B: Timingxxx | xxx30
Appendix B: Timing
Resolution
Horizontal
Frequency
and Polarity
Vertical
Frequency
and Polarity
Pixel
Clock
Scan
Type
Horizontal
Sync
Vertical
Sync
640 x 480
@ 60 Hz
31.469 kHz
Negative
59.940 Hz
Negative
25.175
MHz
39.72 ns
Non-
interlaced
3.813 us
96 dots
.064 ms
2 lines
640 x 480
@ 75 Hz
37.5 kHz
Negative
75 Hz
Negative
31.5 MHz
31.75 ns
Non-
interlaced
2.032 us
64 dots
.08 ms
3 lines
800 x 600
@ 60 Hz
37.879 kHz
Positive
60.317 Hz
Positive
40 MHz
25 ns
Non-
interlaced
3.2 us
128 dots
.106 ms
4 lines
800 x 600
@ 75 Hz
46.875 kHz
Positive
75 Hz
Positive
49.5 MHz
20.2 ns
Non-
interlaced
1.616 us
80 dots
.064 ms
3 lines
1024 x 768
@ 60 Hz
43.363 kHz
Negative
60.004 Hz
Negative
65 MHz
15.38 ns
Non-
interlaced
2.092 us
136 dots
.124 ms
6 lines
1024 x 768
@ 75 Hz
60.023 kHz
Positive
75.029 Hz
Positive
78.75
MHz
12.7 ns
Non-
interlaced
1.219 us
96 dots
.05 ms
3 lines
1152 x 864
@ 60 Hz
54.348 kHz
Positive
60.053 Hz
Positive
80 MHz
12.5 ns
Non-
interlaced
1.2 us
96 dots
.055 ms
3 lines
1152 x 864
@ 75 Hz
67.5 kHz
Positive
75 Hz
Positive
108 MHz
9.26 ns
Non-
interlaced
1.185 us
128 dots
.044 ms
3 lines
1366 x 768
@ 60 Hz
47.712 kHz
Positive
60.015 Hz
Positive
85.5 MHz
11.7 ns
Non-
interlaced
1.31 us
112 dots
.126 ms
6 lines
1366 x 768
@ 75 Hz
60.15 kHz
Positive
75 Hz
Positive
110.195
MHz
9.07 ns
Non-
interlaced
1.307 us
144 dots
.049 ms
3 lines
Table 4.1: Supported Timing
