Dell FPM185 - Page 35

Appendix B: Timingxxx | xxx31
Resolution
Horizontal
Frequency
and Polarity
Vertical
Frequency
and Polarity
Pixel
Clock
Scan
Type
Horizontal
Sync
Vertical
Sync
1280 x 800
@ 60 Hz
49.702 kHz
Negative
59.81 Hz
Positive
83.5 MHz
11.98 ns
Non-
interlaced
1.533 us
128 dots
.121 ms
6 lines
1280 x 800
@ 75 Hz
62.795 kHz
Negative
74.934 Hz
Positive
106.5
MHz
9.39 ns
Non-
interlaced
1.202 us
128 dots
.096 ms
6 lines
1280 x 1024
@ 60 Hz
63.981 kHz
Positive
60.02 Hz
Positive
108 MHz
9.26 ns
Non-
interlaced
1.037 us
112 dots
.047 ms
3 lines
1280 x 1024
@ 75 Hz
79.976 kHz
Positive
75.025 Hz
Positive
135 MHz
7.41 ns
Non-
interlaced
1.067 us
144 dots
.038 ms
3 lines
1140 x 900
@ 60 Hz
55.935 kHz
Negative
59.877 Hz
Positive
106.5
MHz
9.39 ns
Non-
interlaced
1.427 us
152 dots
.107 ms
6 lines
1140 x 900
@75 Hz
70.635 kHz
Negative
74.984 Hz
Positive
136.75
MHz
7.31 ns
Non-
interlaced
1.112 us
152 dots
.085 ms
6 lines
