8. Flip the computer over.
9. Replace the four screws (M2x4) that secure the display assembly to the palm-rest and keyboard assembly.
10. Connect the display cable and close the latch.
11. Adhere the tape that secures the display cable to the system board.
12. Replace the screw (M2x2.5) that secures the display cable to the system board.
Replacing the display assembly
