Replacing the power button with fingerprint
reader
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
NOTE: Applicable only for computers that are shipped with fingerprint reader.
Procedure
1. Using the alignment posts, align the power button on the palm-rest and keyboard assembly.
2. Replace the two screws (M2x2.5) that secure the power button to the palm-rest and keyboard assembly.
3. Adhere the fingerprint reader cable on the palm-rest and keyboard assembly.
Post-requisites
1. Replace the system board.
2. Replace the heat sink.
3. Replace the processor fan.
37
Replacing the power button with fingerprint reader 83
