Removing the display assembly
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Replace the wireless card.
3. Remove the graphics-card fan.
4. Remove the processor fan.
5. Remove the heat sink.
Procedure
1. Remove the screw (M2x2.5) that secures the display-assembly cable to the system board.
2. Peel the tape that secures the display cable to the system board.
3. Open the latch and disconnect the display cable from the system board.
4. Remove the four screws (M2x4) that secure the left and the right hinges to the system board and the palm-rest and keyboard
assembly.
32
64 Removing the display assembly
