Dell IN2010N - Flat Panel Specifications; Preset Display Modes


Flat Panel Specifications
* IN2010N Color Gamut (Typical) is based on CIE1976 (85%) and CIE1931 (72%).
Resolution

Preset Display Modes
1
Video-Red
2
Video-Green
3
Video-Blue
4
GND
5
Self-test
6
GND-R
7
GND-G
8
GND-B
9
Computer 5V/3.3V
10
GND-sync
11
GND
12
DDC data
13
H-sync
14
V-sync
15
DDC clock
Screen type
Active matrix - TFT LCD
Panel type
TN
Screen dimensions
20 inches (20-inch viewable image size)
Preset display area:
Horizontal
Vertical

442.798 mm (17.433 inches)
249.075 mm (9.806 inches)
Pixel pitch
0.2768 mm
Viewing angle
160°(vertical)typical,160°(horizontal)typical
Luminance output
250 CD/m ²(typical)
Contrast ratio
1000 to 1 (typical)
Faceplate coating
Antiglare with hard-coating 3H
Backlight
CCFL edgelight system
Response Time
5 ms typical
Color Depth
16.7 mil colors
Color Gamut
85 %*
Horizontal scan range
30 kHz to 83 kHz (automatic)
Vertical scan range
56Hzto76Hz(automatic)
Maximum preset resolution
1600 x 900 at 60 Hz
Display Mode
Horizontal
Frequency
(kHz)
Vertical
Frequency (Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal/Vertical)
