3 Remove the power and volume-buttons board cable from the routing guides on
the speaker.
1 power and volume-buttons
board cable
2 tapes (2)
4 Using a plastic scribe, lift the speaker and peel off the tape that secures the
power and volume-buttons board cable to the computer base.
5 Release the power and volume-buttons board from the tabs on the computer
base.
37
