Dell Inspiron 13 User Manual

Removing the display assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at dell.com/
regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Remove the fan.
4 Remove the heat sink.
Procedure
1 Disconnect the antenna cables from the wireless card.
2 Remove the screws that secure the display-cable bracket to the system board.
3 Lift the display-cable bracket off the system board.
4 Using the pull tab disconnect the display cable from the system board.
68

Dell Inspiron 13 Specifications

General

Form factor	Convertible (Fold-back screen)
Product type	Hybrid (2-in-1)
Product color	Black, Silver
Market positioning	Business
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	1.7 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.7 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Motherboard chipset	-
Memory slots	1x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
AC adapter included	Yes
Intel segment tagging	Home office
HDD size	2.5 \
HDD speed	5400 RPM
HDD interface	SATA
Storage media	Hybrid-HDD
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Pixel pitch	0.2148 x 0.2148 mm
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0xA16
On-board graphics card model	Intel® HD Graphics 4400
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Audio system	Waves MaxxAudio
Speaker power	2 W
Speakers manufacturer	Waves
Front camera resolution	1280 x 720 pixels
Front camera resolution (numeric)	0.92 MP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Charging port type	DC-in jack
USB 2.0 ports quantity	1
VGA (D-Sub) ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 8.1
Processor code	SR1EF
Processor ARK ID	81016
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology version	1.00
Battery life (max)	- h
Battery recharge time	4 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.34 A
AC adapter output voltage	19.5 V
Password protection type	BIOS
Operating shock	110 G
Operating altitude	-15.2 - 3048 m
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Non-operating vibration	1.3 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	222 mm
Width	330 mm
Height	19 mm
Weight	1660 g
