20 | Removing the Optical-Drive Assembly
3 Remove the screws that secure the optical-drive bracket to
the optical-drive assembly.
4 Remove the optical-drive bracket from the optical-drive assembly.
5 Carefully pry the optical-drive bezel and remove it from the optical-drive assembly.
1 optical-drive bezel 2 optical drive
3 screws (2) 4 optical-drive bracket
3
1
2
4
