90 | Removing the Camera Module
Procedure
1 Remove the screw that secures the camera module to the display back-cover.
2 Disconnect the camera cable from the connector on the camera module.
3 Peel the tape that secures the camera module to the display back-cover.
4 Lift the camera module off the display back-cover.
1 screw 2 camera module
3 tape 4 camera cable
