24 | Removing the Hard-Drive Assembly
3 Using the pull-tab, lift the hard-drive assembly out of the computer base.
4 Remove the screws that secure the hard-drive bracket to the hard drive.
5 Lift the hard-drive bracket off the hard drive.
1 hard-drive assembly 2 pull-tab
1 screws (2) 2 hard-drive bracket
2
1
2
1
