Steps
1. Pry the retention clips securing the memory module until the memory module pops-up.
2. Remove the memory module from the memory-module slot.
NOTE: Repeat step 1 to step 2 to remove any other memory modules installed in your computer.
Installing the memory module
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
NOTE: Latitude 5521 supports two memory slots.
The following image indicates the location of the memory module and provides a visual representation of the installation
procedure.
Removing and installing components
33
