Specifications 159
Size:
Width
64.88 mm (2.55-inch) sensor-active area
Height
48.88-mm (1.92-inch) rectangle
Battery
Ty p e
9-cell hybrid lithium ion (68 WHr)
6-cell "smart" lithium ion (42 WHr)
4-cell "smart" lithium ion (28 WHr)
(optional)
Dimensions:
Depth
77.5 mm (3.05 inches)
Height
19.5 mm (0.76 inch)
Width
123.4 mm (4.86 inches)
Weight 0.32 kg (0.70 lb) (6 cell)
0.23 kg (0.52 lb) (4 cell)
Voltage 14.8 VDC (4 cell)
11.1 VDC (6 cell)
11.1 VDC (9 cell)
Charge time (approximate)
:
Computer off
approximately 1 hour for 80 percent charge
for 4 and 6 cell.
Operating time varies depending on operating conditions
and can be significantly reduced under
certain power-intensive conditions.
See "Battery Performance" on page 27 for
more information.
Fingerprint Reader (optional)
Type UPEK TCS3 TouchStrip™ strip sensor with
CMOS active capacitive pixel-sensing
technology
Power Supply 2.7 V to approx. 3.6 V
Connector 48-ball BGA
Array Size 248 x 2 pixels
Touch Pad
