Dell Latitude E5450 - Page 16

a. base cover
b. battery
c. keyboard trim
d. keyboard
3. Remove the screws that secure the palmrest to the computer.
4. Flip the computer and perform the following steps:
a. Disconnect the following cables from its connectors on the system board [1] [2]:
• LED board
• touchpad board
• USH board
b. Pry the palmrest on its edges to release it from the computer [3]
5. Remove the palmrest from the computer.
16
