Dell Latitude E5450 - Installing the Edp Cable; Removing the Coin-Cell Battery

Installing the eDP cable
1. Fix the eDP cable in its place on the display assembly.
2. Connect the eDP cable to its connector.
3. Install the:
a. display panel
b. display bezel
c. display assembly
d. display-hinge brackets
e. palmrest
f. keyboard
g. keyboard trim
h. hard-drive assembly
i. memory
j. battery
k. base cover
4. Follow the procedures in After Working Inside Your Computer.
Removing the Coin-Cell Battery
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the:
a. base cover
b. battery
c. memory
d. hard-drive assembly
e. keyboard trim
f. keyboard
g. palmrest
35
