Dell Latitude E5450 - Removing the Speakers

4. Install the:
a. system board
b. coin-cell battery
c. display assembly
d. display-hinge brackets
e. palmrest
f. keyboard
g. keyboard trim
h. WWAN
i. WLAN
j. memory
k. hard-drive assembly
l. battery
m. base cover
n. SD card
5. Follow the procedures in After Working Inside Your Computer.
Removing the Speakers
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the:
a. base cover
b. battery
c. memory
d. hard-drive assembly
e. keyboard trim
f. keyboard
g. palmrest
3. Disconnect the speaker cable from its connector on the system board [1] and release the speaker
cables from their routing channels [2].
