Feature Glass Fiber Reinforced
Polymer Cover W/O
Touch
Mag Cover W/O Touch Mag Cover With Touch
Back 23.10 mm (0.91 inch) 22.85 mm (0.90 inch) 23.80 mm (0.94 inch)
Width 334.90 mm (13.19 inches) 334.90 mm (13.19 inches) 334.90 mm (13.19 inches)
Depth 231.15 mm (9.10 inches) 231.15 mm (9.10 inches) 231.15 mm (9.10 inches)
Weight 4.05 lb (1.84 kg) 3.98 lb (1.80 kg) 4.13 lb (1.83 kg)
Table 28. Environmental
Feature Specification
Temperature:
Operating 0 °C to 35 °C (32 °F to 95 °F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
Relative humidity
(maximum):
Operating 10 % to 90 % (non condensing)
Storage 5 % to 95 % (non condensing)
Altitude (maximum):
Operating
0 m to 3048 m (0 ft to 10,000 ft)
0° to 35°C
Non-Operating 0 m to 10,668 m (0 ft to 35,000 ft)
Airborne contaminant level G1 as defined by ISA-71.04–1985
57
