Display Assembly
Dell™Latitude™E5510DiscreteServiceManual
Removing the Display Assembly
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery from the computer.
3. Remove the access panel from the computer.
4. Remove the WLAN card from the computer.
5. Remove the LED cover from the computer.
6. Remove the keyboard from the computer.
7. Disconnect the wireless antennas and remove them from their routing paths.
8. Remove the screws securing the bottom of the display assembly to the computer.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
