Installing the Processor Fan
1. Connect the processor-fan cable.
2. Insert the processor fan into its slot in the computer.
3. Tighten the screws that secure the processor fan to the computer.
4. Install the:
a) base cover
b) battery
5. Follow the procedures in After Working Inside Your Computer .
Removing the Video-Card Fan
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the:
a) battery
b) base cover
3. Remove the screws that secure the video-card fan to the computer. Remove the video-card fan from the computer.
Disconnect the video-card fan cable.
Installing the Video-Card Fan
1. Connect the video-card fan cable.
2. Insert the video-card fan into its slot and tighten the screws to secure it to the computer.
3. Install the:
a) base cover
b) battery
4. Follow the procedures in After Working Inside Your Computer.
Removing the Keyboard Trim
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the battery.
3. Pry up the keyboard trim starting from the top-inner edge.
22

Dell M6700 P22F Specifications

General

Model	Dell Precision M6700
CPU	Up to Intel Core i7-3940XM Extreme Edition
Processor	Intel Core i7
Display	17.3-inch, Full HD (1920x1080)
Graphics	NVIDIA Quadro K5000M or AMD FirePro M6000
RAM	Up to 32GB DDR3
Hard Drive	Up to 1TB HDD or 512GB SSD
Storage	Multiple options including HDD, SSD
Operating System	Windows 7 Professional or Windows 8 Pro
Battery	9-cell (97Wh)
Ports	USB 3.0, HDMI, DisplayPort, eSATA
Wireless	Bluetooth 4.0
