3
Technical Specifications
NOTE: Operate the system at an ambient temperature not higher than 40°C.
CAUTION: Lithium Battery Caution: There is a danger of explosion if the battery is incorrectly
replaced.
NOTE: Replace the battery only with the same or an equivalent type. Dispose of the batteries
according to the manufacturer's instructions.
Table 1. S4810–ON Chassis Physical Design
Parameter Specifications
Height 1.73 inches (4.4 cm)
Width 17.32 inches (44.0 cm)
Depth 18.11 inches (47.6 cm)
Chassis weight with factory-installed components 14.39 pounds (approx.) (6.54 kg)
Rack clearance required
Front: 5 inches (12.7 cm)
Rear: 5 inches (12.7 cm)
Table 2. Environmental Parameters
Parameter Specifications
Operating temperature 32° to 104°F (0° to 40°C)
Operating humidity 10–85 percent (RH), noncondensing
Storage temperature –40° to 158°F (–40° to 70°C)
Relative humidity 10–85 percent, noncondensing
Maximum thermal output 1194 BTH/h
Maximum Altitude No performance degradation to 10,000 feet (3,048
meters)
Shock Meets Bellcore Zone 4 earthquake requirements
(MIL-STD-810)
Table 3. Power Requirements
Parameter Specifications
AC Power supply 100 VAC ~ 240 VAC 50–60 Hz
Maximum current draw per system
4.20 A @ 100 VAC
1.70 A @ 240 VAC
Maximum power consumption 350 Watts (AC)
Typical power consumption 220 Watts (AC)
Technical Specifications
15
