Technical Specifications 23
5
Technical Specifications
Operate the product at an ambient temperature not higher than 40°C.
Lithium Battery Caution: There is a danger of explosion if the battery is
incorrectly replaced.
Replace only with same or equivalent type. Dispose of the
batteries according to the manufacturer's instructions.
Chassis Physical Design
Environmental Parameters
Parameter Specifications
Height 1.71 inches (
43.5 mm
)
Width
17.09
inches (
434
mm)
Depth 18.11 inches (460 mm)
Parameter Specifications
Operating temperature 32° to 113°F (0° to 45°C)
Operating humidity 5 to 90% (RH), non-condensing
Storage temperature –40° to 158°F (–40° to 70°C)
Storage humidity 5 to 90% (RH), non-condensing
Maximum thermal output 419.7 BTU/hr
