26 Installing the Software
To set up the RS-232 console port, follow these steps.
Accessing the RJ-45 Console Port with a DB-9 Adapter
If the DTE has a DB-9 interface, you can connect to the console using an RJ-45
to DB-9 adapter along with the RJ-45 rollover cable.
Table 6-1
lists the pin
assignments.
Step Task
1 Install an RJ-45 copper cable into the console port. Use a rollover cable to
connect the S6000 console port to a terminal server.
2 Connect the other end of the cable to the DTE terminal server.
3 Set the default terminal settings as follows:
• 9600 baud rate
• No parity
• 8 data bits
• 1 stop bit
• No flow control
Table 6-1. Pin Assignments Between the Console and a DTE Terminal Server
Console Port RJ-45 to RJ-45 Rollover Cable RJ-45 to DB-9
Adapter
Terminal Server
Device
Signal RJ-45 Pinout RJ-45 Pinout DB-9 Pin Signal
RTS 1 8 8 CTS
NC 2 7 6 DSR
TxD 3 6 2 RxD
GND 4 5 5 GND
GND 5 4 5 GND
RxD 6 3 3 TxD
NC 7 2 4 DTR
CTS 8 1 7 RTS
