Installing the expansion card
1 Insert the expansion card into the connector on the system board.
2 Press the expansion card until it clicks into place.
3 Close the expansion card latch and press it until it clicks into place.
4 Install the cover.
5 Follow the procedure in After working inside your computer.
Coin cell battery
Removing coin cell battery
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a cover
3 To remove the coin cell battery:
a Press the release latch until the coin cell battery pops out [1].
b Remove the coin cell battery from the connector on the system board [2].
Removing and installing components
11
