Installing the M.2 PCIe SSD
1 Insert the M.2 PCIe SSD to the connector.
2 Press the blue tab to secure the M.2 PCIe SSD.
3 Install the:
a Optical drive
b 2.5–inch drive assembly
c bezel
d cover
4 Follow the procedure in After working inside your computer.
Heat sink assembly
Removing heat sink assembly
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a cover
b bezel
c 2.5–inch drive assembly
d optical drive
Removing and installing components
21
