4 To remove the optical drive module:
a Pull the tab upward to release the module [1].
b Holding the tab, disconnect the optical drive cables [2].
c Slide and lift the optical drive module away from the computer [3].
5 To remove the optical drive:
a Slide the tab to release the optical drive [1].
b Push the optical drive away from the module [2][3].
Removing and installing components
19
