4. Route all the cables through the routing clips.
5. Align the cables with the pins on connectors on the system board and connect the following cables to the system board:
a. SATA [1]
b. System power [2]
c. Speaker [3]
d. Hard drive data and optical drive data [4]
e. CPU power [5]
