Dell OptiPlex 7420 - GPU-Integrated

Table 17. Display specifications(continued)
Description Option one Option two
Display-panel technology
In-Plane Switching (IPS) In-Plane Switching (IPS)
Display-panel dimensions (active area):
Height
296.46 mm (11.67 in.) 296.46 mm (11.67 in.)
Width
527.04 mm (20.75 in.) 527.04 mm (20.75 in.)
Diagonal
604.70 mm (23.81 in.) 604.70 mm (23.81 in.)
Display-panel native resolution
1920 x 1080 1920 x 1080
Luminance (typical)
250 nits 300 nits
Megapixels
2.07 2.07
Color gamut
99% (sRGB) 99% (sRGB)
Pixels Per Inch (PPI)
92 92
Contrast ratio (min.)
● 700:1, minimum
● 1000:1, typical
● 700:1, minimum
● 1000:1, typical
Response time (max.)
● 25 ms, minimum
● 14 ms, typical
● 20 ms, minimum
● 14 ms, typical
Refresh rate
60 Hz 60 Hz
Horizontal view angle
● +/- 85 degrees, minimum
● +/- 89 degrees, typical
● +/- 85 degrees, minimum
● +/- 89 degrees, typical
Vertical view angle
● +/- 85 degrees, minimum
● +/- 89 degrees, typical
● +/- 85 degrees, minimum
● +/- 89 degrees, typical
Pixel pitch
0.27 mm 0.27 mm
Power consumption (maximum)
14.11 W 17.26 W
Anti-glare vs glossy finish
Anti-glare Anti-glare
GPU—Integrated
The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your OptiPlex
All-in-One 7420.
Table 18. GPU—Integrated
Controller External display support Memory size Processor
Intel UHD Graphics 710
● One DisplayPort++ 1.4a
port (5120 x 3200 at 60
Hz)
● One HDMI-out 2.1 port
(4096 x 2160 at 60
Hz), only for computers
shipped with a High
Performance processor
Shared system memory Intel 300/300T
24 Specifications of OptiPlex All-in-One 7420
