Feature Specification
Mini-Tower four 7-pin connectors
Desktop three 7-pin connectors
Small Form Factor three 7-pin connectors
Ultra Small Form Factor two 7-pin connectors
Memory:
Mini-Tower, Desktop, Small Form Factor four 240-pin connectors
Ultra Small Form Factor two 240-pin connectors
Internal USB:
Mini-Tower and Desktop one 10-pin connector
Small Form Factor and Ultra Small Form Factor none
System Fan one 5-pin connector
Front panel control:
Mini-Tower, Desktop, Small Form Factor one 6–pin and two 20–pin connector
Ultra Small Form Factor one 14–pin, one 20–pin and one 10–pin
connector
Thermal Sensor one 2-pin connector
Processor one 1155-pin connector
Processor Fan one 5-pin connector
Service mode jumper one 2-pin connector
Password clear jumper one 2-pin connector
RTC reset jumper one 2-pin connector
Internal speaker one 5-pin connector
Intruder connector one 3-pin connector
Power connector:
Mini-Tower, Desktop, Small Form Factor one 24-pin and one 4-pin connector
Ultra Small Form Factor one 8-pin, one 6-pin, and one 4-pin
connector
Table 26. Controls and Lights
Feature Specification
Front of the computer:
Power button light White light — Solid white light indicates power-on state; blinking
white light indicates sleep state of the computer.
61
