Dell OptiPlex 990 - Chassis Intrusion Switch Service; Removing the Chassis Intrusion Switch

Chassis Intrusion Switch 7
Removing the Chassis Intrusion Switch
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the cover .
3. Remove the front bezel .
4. Remove the drive cage .
5. Disconnect the intrusion cable from system board.
6. Slide the intrusion switch over and remove it off the bracket.
21
