Control Panel 18
Removing the Control Panel
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove the
cover
.
3. Remove the
front bezel
.
4. Remove the
drive cage
.
5. Remove the
memory
.
6. Disconnect the control panel cable from the system board.
7. Unthread the control panel-speaker cable from the chassis clip.
8. Remove the screw that secures the control panel board.
47
