Removing and installing Customer
Replaceable Units (CRUs)
The replaceable components in this chapter are Customer Replaceable Units (CRUs).
CAUTION: Customers can replace only the Customer Replaceable Units (CRUs) following the safety precautions
and replacement procedures.
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Side cover
Removing the side cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
About this task
The following image indicates the location of the side cover and provides a visual representation of the removal procedure.
Steps
1. Loosen the two captive screws that secure the side cover to the chassis.
2. Slide the side cover towards the back of the computer.
3. Lift the side cover from the chassis.
5
Removing and installing Customer Replaceable Units (CRUs) 37
