Dell OptiPlex Small Form Factor 7010 User Manual

About this task
The following image indicates the location of the processor and provides a visual representation of the removal procedure.
WARNING: The processor might still be hot after the computer is shut down. Allow the processor to cool down
before removing it.
Steps
1. Press the release lever down and then push it away from the processor to release it from the securing tab.
2. Extend the release lever completely and open the processor cover.
CAUTION:
When removing the processor, do not touch any of the pins inside the socket or allow any objects
to fall on the pins in the socket.
3. Gently lift the processor from the processor socket.
Installing the processor
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the processor and provides a visual representation of the installation procedure.
Removing and installing Field Replaceable Units (FRUs)
79

Dell OptiPlex Small Form Factor 7010 Specifications

General

Chipset	Intel Q670
Memory Slots	2 DIMM slots
Optical Drive	Optional DVD+/-RW
Form Factor	Small Form Factor
Processor Options	Intel Core i3, i5, i7
Memory	Up to 64GB
Storage Options	2.5-inch HDD/SSD, M.2 SSD
Graphics	Intel UHD Graphics, optional discrete GPU
Expansion Slots	1 PCIe x16, 1 PCIe x4
Ports	USB 3.2, USB 2.0, HDMI, DisplayPort, VGA, audio, Ethernet
Operating System	Windows 11 Pro
Dimensions	290 x 92.6 x 292.8 mm (11.4 x 3.6 x 11.5 inches)
