DELL™ OPTIPLEX™ XE2 TECHNICAL GUIDEBOOK
19
AUDIO
COMMUNICATIONS - INTEGRATED INTEL® I217
NOTE : MT su p p o r ts full h e i ght ( FH) card s and SF F s uppo rt s lo w p r ole (L P) c ard s.
INTEGRATED REALTEK ALC3220 HIGH DEFINITION AUDIO
MT SFF
High Denition Stereo support X X
Number of channels 2
Number of Bits / Audio resolution 16, 20, and 24-bit resolution
Sampling rate (recording/playback)
Support 44.1K/48K/96K/192 kHz
sample rates
Signal to Noise Ratio
98 dB DAC outputs, 90 dB for
ADC inputs
Analog Audio X X
Dolby Digital
THX
Digital out (S/PDIF)
Audio Jack Impedance
Microphone 40K ohm~60K ohm
Line-In 40K ohm~60K ohm
Line-Out 100~150 ohm
Headphone 1~4 ohm
Internal Speaker Power Rating 2Watt (peak) / 1Watt (average)
INTEGRATED INTEL® I217 GIGABIT1 ETHERNET LAN 10/100/1000
MT SFF
External Connector Type RJ45
Data Rates supported 10/100/1000 Mbps
Controller Details
Controller bus architecture
PCIe-based interface for S0 state,
SMBus for Sx low power state
Integrated memory N/A
Data transfer mode (example Bus-Master DMA) N/A
Power consumption (full operation per data rate connection speed) 535mW (Max.)
Power consumption (standby operation) 176mW (Max.)
IEEE standards compliance (example 802.1P) 802.3
Hardware Certications (example FCC, B, GS mark…) N/A
Boot ROM Support EEPROM (located in SPI)
Network Transfer Mode (example Full Duplex, Half Duplex)
Network Transfer Rate (example 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps
10 Mb (full/half-duplex)
100 Mb (full/half-duplex)
1000 Mb (full-duplex)
