DELL™ OPTIPLEX™ XE2 TECHNICAL GUIDEBOOK
26
GRAPHICS/VIDEO CONTROLLER
NOTE : MT su p p o r ts full h e i ght ( FH) card s and SF F s uppo rt s lo w p r ole (L P) c ard s.
1
Up to 1.7 GB of system memory may be allocated to support integrated graphics, depending on operating system, system memory size and other
factors.
2
DVI and VGA can be used concurrently for multi-monitor display in DOS. The DisplayPort controller does not support multi-monitor display in
DOS
Onboard Graphics.
Intel HD Graphics 4600 [with iCore Dual/Quad core CPU-GPU combo]
MT SFF
Bus Type Integrated
GPU core clock
Gen6 Core Intel® HD Graphics /
HD Graphics 4600 @ 1250MHz
Frame Buer Memory (onboard and shared) Size and Speed
Depends on available system
memory (Up to 1.7GB with 4GB
system Memory)
Overlay Planes Yes
Maximum Color Depth 32 bit
Maximum Vertical Refresh Rate 75 Hz
Multiple Display Support Yes
Operating Systems Graphics/ Video API Support OpenGL 4.0/DirectX 11.1
Supported Resolutions and Max Refresh Rates (Hz) (Note: Analog and/or digital)
Up to 3840x2160 @ 60Hz (DP)
Up to 2560x1600 @ 60Hz (HDMI)
Up to 4096x2304 @ 24Hz (HDMI)
Up to 1920x1200 @ 60Hz
(DVI&VGA)
External Connectors VGA, DisplayPort
DisplayPort
Bus Type DDPC
Maximum supported resolution Up to 3840x2160 @ 60Hz
Maximum power consumption N/A
External connectors DisplayPort
