6 Install the:
a Front bezel
b Side cover
7 Follow the procedure in After working inside your computer.
Paměťový modul
Removing memory module
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Side cover
b Front bezel
c HDD assembly
d Hard drive and optical drive module
3 To remove the memory module:
a Pry open the retention tabs from both sides to lift the memory module from the connector [1].
b Remove the memory module from the system board [2].
34
Demontáž a opětovná montáž
