Dell OptiPlex XE3 - Installing the Memory Module

Installing the memory module
1 Align the notch on the memory module with the tab on the memory module connector.
2 Insert the memory module into the memory module socket [1].
3 Press the memory module until the memory module retention tabs click into place [2].
