Dell OptiPlex XE3 - Page 53

3 Connect the power cable to the connector on the system board [1].
4 Route the CPU power cable through the retention clips [2,3].
5 Connect the CPU power cable to the connector on the system board [4].
Demontáž a opětovná montáž
53
