Installing the I/O board
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
NOTE:
A RJ-45 Network Port assembly for the I/O board is required.
If you are replacing the I/O board, transfer the existing RJ-45 Network Port assembly to the replacement I/O board.
The following image(s) indicate the location of the I/O board and provides a visual representation of the installation procedure.
Removing and installing components 41
