Steps
1. Release the latch of the keyboard backlit connector on the system board and disconnect the keyboard backlit cable.
2. Release the latch of the keyboard connector on the system board and disconnect the keyboard cable.
3. Release the latch of the touchpad connector on the system board and disconnect the touchpad cable.
4. Remove the speakers cable from the routing guides on the palm-rest and keyboard assembly.
5. Disconnect the speaker cable.
6. Lift the speakers along with their cables off the palm-rest and keyboard assembly.
Installing the speakers
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
Removing and installing components
45
