Table 25. Screw list(continued)
Component Screw type Quantity Image
Power button with fingerprint
reader assembly
M1.6x2 1
System board M1.6x2 6
M1.6x3 1
Major components of Latitude 9450 2-in-1
The following image shows the major components of Latitude 9450 2-in-1.
Figure 16. Explode view
1. Base cover
2. Speaker
3. WWAN card shielding cover
