30  │  About your monitor
Electrical specifications
Model P2225H/P2425H/P2425H WOST/P2425/
P2725H/P2725H WOST
Video input signals • Analog RGB, 0.7 V ± 5%, positive polarity at 75 Ω
input impedance
• HDMI 1.4 (TMDS)*/DisplayPort 1.2, 600 mV for
each differential line, 100 ohm input impedance
per differential pair
AC input voltage/
frequency/current
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz /
1.5
A (typical)
Inrush current • 120 V: 30 A (Max.) at 0°C (cold start)
• 240 V: 60 A (Max.) at 0°C (cold start)
Power consumption
P2225H •0.3 W (Off mode)
1
•0.3 W (Standby mode)
1
•10.9 W (On mode)
1
•60 W (Max.)
2
•10.1 W (P
on
)
3
• 32.2 kWh (TEC)
3
P2425H/P2425H WOST •0.3 W (Off mode)
1
•0.3 W (Standby mode)
1
• 11.7 W (On mode)
1
•65 W (Max.)
2
•12.0 W (P
on
)
3
• 38.4 kWh (TEC)
3
P2425 •0.3 W (Off mode)
1
•0.3 W (Standby mode)
1
•13.6 W (On mode)
1
•74 W (Max.)
2
• 12.2 W (P
on
)
3
•38.5 kWh (TEC)
3
