Operating the monitor │ 83
Using the tilt, swivel, pivot and height adjustment
NOTE: The following instructions are applicable only for attaching the
stand that was shipped with your monitor. If you are attaching a stand
that you purchased from any other source, follow the setup
instructions that were included with the stand.
Tilt and swivel adjustment
With the stand attached to the monitor, you
can tilt and swivel the monitor for the
most comfortable viewing angle.
NOTE: The stand assembly is not pre-installed when the monitor is
shipped from the factory.
Height adjustment
NOTE: The stand extends vertically up to 150 mm. The following image
illustrates how to extend the stand vertically.
