Disassembly and reassembly
Topics:
• Recommended tools
•
Screw size list
• Base cover
• Battery
• Solid State Drive
• Keyboard lattice and Keyboard
• Audio board
• Power connector port
• Coin-cell battery
• Speaker
• Touchpad
• System board
• Display assembly
• Display bezel
• Display panel
• Camera
• Display hinges
• Palm rest
Recommended tools
The procedures in this document require the following tools:
● Phillips #0 screwdriver
● Phillips #1 screwdriver
● Plastic scribe
NOTE: The #0 screw driver is for screws 0-1 and the #1 screw driver is for screws 2-4.
Screw size list
Table 14. Screw size list
Component
M2.5x7
M2x3
M2.5x 2.5
Big Head
M2X2 Big
Head
M2.5x5
M2.5X3.5
Base cover 7
Battery 3
System board 5
M.2 SSD card 1
Audio board 1
Power connector port 2
4
Disassembly and reassembly 23
