Dell P3424WEB Quick Start Guide

3
DELL P3424WEB
S14
S15
S18
S16
S17
Lift up the middle bezel frame from the panel and put
it into a fixture, then tear off all the tape and mylar
tape for releasing the LED board away from the
middle frame.
Release the assembled camera unit from the
probers of the middle frame and put it aside for later
disassembling.
(No.1~18 screw size=M3x4,Torque=3±0.5kgfxcm)
Tear off 2pcs aluminum foil to release the Mic boards
Use a Philips-head screwdriver to remove 18pcs
screws for unlocking the middle frame with the panel.
Tear off 1pcs tape and disconnect the eDP cable
away from the connector of the panel, then lift up
and take away the chassis and put it aside.
(No.1~4 screw size=M2x3.3,Torque=1±0.2kgfxcm)
Use a Philips-head screwdriver to remove 4pcs
screws for unlocking the left and right Mic boards
with the middle frame, then release the two Mic
boards away from the middle frame.
10
7
9
3
4
5
6
2
1
11
8
2
6
5
18
2
3
6
3
1
2
4
